MP100

מגברים

Mcintosh

Moving Coil & Moving Magnet inputs
Analog outputs + USB for ripping to computer

The MP100 is the first dedicated phono preamplifier from McIntosh and is designed to help both new and experienced vinyl lovers get the most fidelity, performance and – most importantly – enjoyment from their albums.

ELECTRONIC SPECIFICATIONS

Total Harmonic Distortion 0.005%
Frequency Response ±0.3dB from 20Hz to 20,000Hz
Maximum Volts Out (Balanced / Unbalanced) 16/8 V RMS
Input Impedance Moving Coil: 25, 50, 100, 200, 400 or 1k Ohms; 470pF Moving Magnet: 47k Ohms; 50, 100, 150, 200, 300 or 400pF
Phono Voltage Gain Moving Coil: 60dB Moving Magnet: 40dB
Signal To Noise Ratio Moving Coil: 78dB Moving Magnet: 80dB
Maximum Input Signal (Moving Coil) 8mV
Maximum Input Signal (Moving Magnet) 80mV
Maximum Input Signal (Balanced) N/A
Maximum Input Signal (Unbalanced) N/A
Sensitivity Phono (Moving Coil) 1mV
Sensitivity Phono (Moving Magnet) 10mV
Sensitivity (Balanced) N/A
Sensitivity (Unbalanced) N/A
Rated Output 2V Balanced 1V Unbalanced
Output Impedance 200 Ohms Balanced 100 Ohms Unbalanced
Phono Equalization Curves 1: RIAA
Noise Filters 0
Phono Profiles 0
